Specification
| SPECIFICATIONS | ||||||||
| MODEL | CH7151AB21 | CH7151AB22 | CH7151AB24 | CH7151AB62 | CH7151AB64 | |||
| DIMENSIONS | ||||||||
| Overall length (mm) | 4095 | |||||||
| Overall width(mm) | 1750 | |||||||
| Overall height(mm) | 1545, 1583（with luggage rack) | |||||||
| Wheelbase (mm) | 2519 | |||||||
| Tread | Front (mm) | 1467 | ||||||
| Rear(mm) | 1453 | |||||||
| Suspension | Front (mm) | 861 | ||||||
| Rear(mm) | 715 | |||||||
| Minimum turning radius (m) | 5.45 | |||||||
| Minimum ground clearance(mm) | 150 | |||||||
| WEIGHT | ||||||||
| Curb weight(Front axle/Rear axle/Vehicle)( kg) | 1139 | 1153 | ||||||
| Gross vehicle weight(Front axle/Rear axle/Vehicle)( kg) | 1539 | 1553 | ||||||
| ENGINE | ||||||||
| Model | A151 | |||||||
| Type | DOHC | |||||||
| Piston displacement ( ml) | 1499 | |||||||
| Bore x stroke (mm) | 75×84.8 | |||||||
| Compression ratio | 10.5:1 | |||||||
| Maximum output( kW/rpm) | 85/6000 | |||||||
| Maximum torque(Nm/rpm) | 142/3800 | |||||||
| Maximum speed(Km/h) | 160 | |||||||
| TRANSMISSION | ||||||||
| Type | MT | AT | AT | |||||
| Gear ratio | 1st | 3.308 | 2.875 | |||||
| 2nd | 1.913 | 1.568 | ||||||
| 3rd | 1.258 | 1 | ||||||
| 4th | 0.943 | 0.697 | ||||||
| 5th | 0.763 | - | ||||||
| Reverse | 3.231 | 2.3 | ||||||
| Final gear ratio | 4.158 | 4.375 | ||||||
| CHASSIS | ||||||||
| Suspension | Front | MacPherson independent suspension | ||||||
| Rear | H type torsion beam suspension suspension | |||||||
| Brakes | Front | Disc | ||||||
| Rear | Disc | |||||||
| Tyres | 195/55R15; 205/50R16 | |||||||
| CAPACITY | ||||||||
| Seating | 5 | |||||||
| FUEL TANK | 45L | |||||||
