| SPECIFICATIONS | ||||||
| FREEDOM | CH6390LE4 | CH5026XXYLE4 | ||||
| Type | STD | SD | STD1 | STD2 | SD1 | SD2 |
| DIMENSIONS | ||||||
| Overall length (mm) | 3868 | |||||
| Overall width(mm) | 1528 | |||||
| Overall height(mm) | 1848 | |||||
| Wheelbase (mm) | 2405 | |||||
| Tread | Front (mm) | 1310 | ||||
| Rear(mm) | 1310 | |||||
| Minimum turning radius (m) | 5 | |||||
| WEIGHT | ||||||
| Curb weight kg | 1015 | |||||
| Gross vehicle weight kg | 1670 | |||||
| ENGINE | ||||||
| Type | DA465QE-1A（MPI,8 valves） | |||||
| Bore x stroke (mm) | 69.71×81.2 | |||||
| Compression ratio | 10.5:1 | |||||
| Maximum output( kW/rpm) | 61/6000 | |||||
| Maximum torque(Nm/rpm) | 112/4400 | |||||
| Maximum speed(Km/h) | ≥90 | |||||
| TRANSMISSION | ||||||
| Type | MT | |||||
| Gear ratio | 1st | 3.769 | ||||
| 2nd | 1.948 | |||||
| 3rd | 1.424 | |||||
| 4th | 1 | |||||
| 5th | 0.795 | |||||
| Reverse | 3.466 | |||||
| Final gear ratio | 4.778 | |||||
| Steering | Rack and pinion | |||||
| Suspension | Front | MacPherson strut and coil spring | ||||
| Rear | Non━isolated trailing and leaf spring | |||||
| Brakes | Front | Ventilated disc | ||||
| Rear | Drum,leading and trailing | |||||
| Tyres | 165/70R13LT | |||||
| CAPACITY | ||||||
| RHD | none | |||||
| Fuel tank | 37L | |||||
